function outputs
The six CVs mean the following:
• is said to have defined what effect the output: Mode Select.
• ON and OFF delay: Here you can choose whether the output should be active
immediately after pressing the function key, or to switch only after a delay. The
same can delay the switch-off are defined after shutdown.
• Automatic shutdown: Sometimes it is useful (for example, for digital clutches)
when a function output automatically turns off after a certain time (eg digital
couplers), even if the function key is still on. The maximum on-time can be
defined here.
• Brightness: The brightness of each individual output in 32 stages (0 to 31)
• Special features CV1 to CV3: Certain light effects benö- term more options to
the exact function to be determined. This information will be made there.
12.5.1. Possible light effects and possibilities
The following lighting effects are available:
• Dimmable light: A normal continuous output consumer cher. If the dimmer
function, the brightness is duced to 50% re-.
• Dimmable light "on / Fade Out": Here the output is switched on and slowly
mimics the slow glowing from Öllam- pen or very old light bulbs to. If the dimmer
function, the brightness is reduced to 50%.
• Firebox: Here a normal firebox lighting is simulated.
• Intelligent firebox: Here is an "intelligent" Feuerbüch- senbeleuchtung is
simulated, the intensity of which will change if the global logic function "firebox"
is active.
• Single Strobe: This mimics a single flash. The frequency can be set.
• Double Strobe: This after a double flash. The frequency can be set.
function outputs
• Rotary Beacon: This is a typical light effect for diesels of the 60's and 70's.
• Prime Stratolight: The sequel to the Rotary Beacon for America- American diesel locomotives
• Ditch Light Type1: If selected, the output is tet eingeschal- if he is not to blink.
• Ditch Light Type 2: This is the output or is usually switched off, it flashes.
• Oscillator: A required for the US warning.
• Flashing: The "classic" flashlight. The frequency can be Set Default.
• Mars Light: This simulates the familiar warning from the US.
• Gyra Light: Similar to a Mars light, but more slowly.
• FRED: "Flashing End of Train Device": Mimics the bottom AME rikanischer
trains to.
• Neon: Framed typical Einschaltcharakter a neon lamp to
• Energy saving lamp: Imitate the typical Einschaltcharakter a modern
energy-saving lamp. The following special functions are available:
• Fan control: Here is a small electric motor is high and slow down. Is used for fan
motors continue to run long.
• Seuthe® smoke generator: The intensity is controlled HE down during standstill.
• Steam-Trigger: The output generates a control pulse for clocked smoke
generator, from KM-1® (aftermarket) or mass soth®.
• Power: At the exit of an RC servo depends. Not available for all out- puts are
available.
• Conventional clutch function: Use this function to drive Krois® couplings. Also in
connection with the automatic check-in and prints.
• ROCO® clutch function: Use this function to
