Figure 9: General connection diagram LokSound 5 (Example wiring)
Figure 10: Wiring Diagram for LokSound micro 5 (wiring example, free wiring)
violet
DC motor
AUX2 AUX1
light
back
light
front
violet green yellow White
Gray
orange
Rail connection
on the left
Rail
connection
right
Red
Black
brown
brown
blue
blue
green
white
black
orange
gray
yellow
red
Speaker 4 ~ 8
Ohm
blue
DC motor
AUX2
AUX1
light front
violet
green
yellow
White
orange
Rail connection on
the left
Rail
connection
right
Red
Black
brown
Speaker 4 ~ 8
Ohm
brown
White
yellow
gray
orange
light back
Wiring diagram LokSound
6.8.1. Wiring diagram LokSound / LokSound micro
For wiring flexible printed circuit board right on top cut with a sharp utility knife
Installing the decoder
--"-------------------------------------
