78
function outputs
Standard mapping LokSound decoder 5 line
condition block Description Physical outputs Logical Functions sound functions
1
FS, fwd Booth, forward
2 FS, rev Stand, reverse
3 FF, fwd Driving forward
4 FF, rev Ride backward
5 F0, fwd Light button, forward
Front light
6 F0, rev Light button, backward light back
7 F1 F1 key Sound Slot 1, Slot 2 sound (road noise)
8th F2 F2 Sound Slot 3
9 F3 F3 Sound Slot 4
10 F4 F4 Sound Slot 5
11 F5 F5 Heavy load
12 F6 F6 Maneuvering, braking function 3, Alternative load
13 F7 F7 Sound Slot 15
14
F8 F8 AUX1 [1]
15 F9 F9 Sound Slot 9
16 F10 F10 Sound Slot 10
17 F11 F11 Sound Slot 8
18 F12 F12 Brake function 1 Sound Slot 22
19 F13 Not F5 Press F13, Non-F5 Shift Mode 2
20 F14 Press F14 Sound Slot 7
21 F15 Press F15 Smoke generator (ESU, KM-1, Kiss)
22 F16 Press F16 Sound Slot 12
23 F17 Press F17 Sound slots 17
24 F18 Press F18 Sound Slot 14
25 F19 Press F19 Sound Slot 16
26 F20 Press F20 Sound Slot 18
27 F21 Press F21 Sound Slot 19
28 F22 Press F22 Sound Slot 20
29 F23 Press F23 Sound Slot 21
30 F24 Press F24 Sound Slot 6
31 Not F25 Press F25 From Sound Slot 13
32 F26 Press F26 AUX2 [1]
33 F27 Press F27 sound fader
34 F28 Press F28 disable brake noise
35 F29 Press F29 Brake function 2
36 F30 Press F30 Sound Slot 11
37 F31 Press F31 AUX3
