function outputs function outputs
light effect
Mode Select
On / switch-off
delay
Automatic shutdown
brightness
Special Function CV1
Special Function CV 2 Remarks
value Phase exchange Grade XING Rule 17 Fw Rule 17 Rev low beam LED Fashion
dimmable light 1 0 - 255 0 - 255 brightness 0 - 31 4 8th 16 128 Available on all outputs
Dimmable light (dimming on.) 2 0 - 255 0 - 255 brightness 0 - 31 4 8th 16 128 Available on all outputs
firebox 3 0 - 255 0 - 255 brightness 0 - 31 128 Available on all outputs
Intelligent fire Books 4 0 - 255 0 - 255 brightness 0 - 31 128 Available on all outputs
Single strobe 5 0 - 255 0 - 255 brightness 0 - 31 1 2 128 Available on all outputs
Double strobe 6 0 - 255 0 - 255 brightness 0 - 31 1 2 128 Available on all outputs
Rotary Beacon 7 0 - 255 0 - 255 brightness 0 - 31 1 2 128 Available on all outputs
Stratolight 8th 0 - 255 0 - 255 brightness 0 - 31 1 2 128 Available on all outputs
Ditch Light Type 1 9 0 - 255 0 - 255 brightness 0 - 31 1 2 128 Available on all outputs
Ditch Light Type 2 10 0 - 255 0 - 255 brightness 0 - 31 1 2 128 Available on all outputs
Oscillator 11 0 - 255 0 - 255 brightness 0 - 31 1 2 128 Available on all outputs
turn signal 12 0 - 255 0 - 255 brightness 0 - 31 1 2 Available on all outputs
Marslight 13 0 - 255 0 - 255 brightness 0 - 31 1 2 128 Available on all outputs
Gyra Light 14 0 - 255 0 - 255 brightness 0 - 31 1 2 128 Available on all outputs
FRED 15 0 - 255 0 - 255 brightness 0 - 31 1 2 128 Available on all outputs
neon lamp 16 0 - 255 0 - 255 brightness 0 - 31 Start time (0 - 255) Available on all outputs
Energy saving lamp 17 0 - 255 0 - 255 brightness 0 - 31 Start time (0 - 255) Available on all outputs
Single Strobe Random 18 0 - 255 0 - 255 brightness 0 - 31 Available on all outputs
ESU coupling 1 (compatibility) 21 Only AUX7, AUX15
ESU clutch 2 (compatibility) 21 Only AUX8, AUX16
Smoke generator (Sound controlled) 22
Fan control heating control 31 30
Available on all outputs
Fan function (ventillátor) 23 0 - 255 0 - 255 Fan speed 0 - 31 acceleration time (0 - 31) Braking time (0 - 31) Available on all outputs
Seuthe® smoke generator 24 0 - 255 0 - 255 heat level in the state 0 - 31 Heating stage at speed level 1 (0 - 31) Heating stage at Vmax (0 - 31) Available at all outputs
Steam trigger (output) 25 0 - 255 0 - 255 Strength of the steam surge 0 - 31 Strength of the blower (0-31) Timeout (0-31) Available on all outputs
Smoke generator with external board 26 0 - 255 0 - 255
For KM-1 BR41 / 44 Lok All other KM-1 locomotives
All Kiss locomotives All ESU smoke generators
0123
only AUX1
Servo1, Servo2 Servo3, Servo4 Servo5, Servo6
27 0 - 255 0 - 255
Term "A"
0-63 Term "B"
Special Function CV3
End position "A" (0-63) End position "B" (0-63)
Servo1 only AUX15, Servo2 only AUX16 Servo3
only AUX17, Servo4 only AUX18 Servo5 only
AUX11, Servo6 only AUX12
Conventional clutch function 28 0 - 255 0 - 255 Coupling strength (0 - 31) Available on all outputs
ROCO® clutch function (**) 29 0 - 255 0 - 255 Only AUX1 [1], AUX1 [2], AUX2 [1], AUX2 [2]
Pantographensteuerung 30 0 - 255 0 - 255 End position pantographs 0 - 15 Only AUX9, AUX10 for Engineering Edition
Power Pack Control 31 0 - 255 0 - 255 Available on all outputs.
