22
Installing the decoder
Figure 6: LokSound 5 with PluX22 interface
58412 LokSound 5 PluX22
AUX9, AUX10 are logic level outputs and inputs AUX11, AUX12
are logic level outputs
1
11
22
---- AUX8 (Power)
---- AUX7 (Power)
---- AUX6 (Power)
---- AUX5 (Power)
---- AUX4 (Power)
---- AUX 3 (Power)
---- VCC
---- AUX10 Logic Level / wheel sensor
---- GND
---- AUX9 Logic Level / PwrPackCtrl
---- U + (+ pole)
AUX6 (Power) 21
AUX4 (Power) 19
speaker 2 # 17 speaker
# 1 15
Rear light 13
Indexpin 11 U
+ (+ pole) 9 Light
front 7
GND 5
AUX12 / Susi Clk / Servo6 3
AUX10 / wheel sensor 1
22 AUX7 (power) 20 AUX5
(Power) 18 AUX2 (Power) 16
AUX1 (Power) 14 left track
connection 12 right track
connection 10 to the left motor port
connection right motor 8 6 Control
4 AUX11 Cap / Susi Dta / Servo5
2 AUX3
1
22
21
2
AUX9 Default: PwrPackCtrl
