37
LokSound 5 LokSound 5 LokSound 5 LokSound 5 LokSound micro 5 LokSound micro 5 LokSound 5 l LokSound XL 5
6 or 8 pole 21MTC 21MTC "MKL" PluX22 6 or 8 pole Next18 / PluX16 pin header Pin header / screw
light front power power power power power power power power
light back power power power power power power power power
AUX1 power power power power power power power power
AUX2 power power power power power power power power
AUX3
Pad: Power Pad: Power Pad: Power Pad: Power power power
21MTC: Logic Level 21MTC: Power PluX22: Power Next18: Logic Level / Susi Dta / Servo6
AUX4
Pad: Power Pad: Power Pad: Power Pad: Power power power
21MTC: Logic Level 21MTC: Power PluX22: Power Next18: Logic Level / Susi Clk / Servo5
AUX5
Pad: Power Pad: Power Pad: Power Pad: Power Pad: Power Pad: Power power power
21MTC: Logic Level 21MTC: Logic Level PluX22: Power
AUX6
Pad: Power Pad: Power Pad: Power Pad: Power Pad: Power Pad: Power power power
21MTC: Logic Level 21MTC: Logic Level PluX22: Power
AUX7
Pad: Power Pad: Power Pad: Power Pad: Power Pad: Logic Level (PwrPackCtrl) Pad: Logic Level (PwrPackCtrl) power power
21MTC: Logic Level 21MTC: Logic Level PluX22: Power
AUX8
Pad: Power Pad: Power Pad: Power Pad: Power power power
21MTC: 21MTC: PluX22:
AUX9
Pad: Logic Level (PwrPackCtrl) Pad: Logic Level (PwrPackCtrl) Pad: Logic Level (PwrPackCtrl) Pad: Logic Level (PwrPackCtrl) power power
AUX10 21MTC: Logic Level / wheel sensor 21MTC: Logic Level / wheel sensor PluX22: Logic Level / wheel sensor Logic Level / wheel sensor O'Power
AUX11 21MTC: Logic Level / Susi Dta / Servo5 21MTC: Logic Level / Susi Dta / Servo5 PluX22: Logic Level / Susi Dta / Servo5 Logic Level / Susi Dta / Servo5 Logic Level / Susi Dta / Servo5
AUX12 21MTC: Logic Level / Susi Clk / Servo6 21MTC: Logic Level / Susi Clk / Servo6 PluX22: Logic Level / Susi Clk / Servo6 Logic Level / Susi Clk / Servo6 Logic Level / Susi Clk / Servo6
AUX13 Logic level (PwrPackCtrl) Logic level (PwrPackCtrl)
AUX14 AUX15
Logic Level / Servo1
AUX16 Logic Level / Servo2
AUX17 Logic Level / Servo3 Logic Level / Servo3
AUX18 Logic Level / Servo4 Logic Level / Servo4
Smoke Unit heater OK
Smoke Unit fan motor OK
input wheel sensor 21MTC: As an alternative to AUX10 21MTC: As an alternative to AUX10 PluX22: As an alternative to AUX10 OK OK
Input Sensor 1 OK OK
Input Sensor 2 OK OK
input MotorOff OK
Input Smoke Unit temperature OK
