ES581.4 - User’s Guide 15
ETAS Hardware Description
2.3 Applications
The ES581.4 can be used for the following tasks:
• Connection of external devices to INCA PC using the CAN interface
• ECU calibration with CAN bus interface
• ECU diagnostics with CAN bus interface and J2534 Pass Thru Interface
• Flash programming of ECUs
• Recording and acquisition of communication data with application soft-
ware
For example, the ES581.4 can be connected to a vehicle CAN via the diagnostics
service port. So it's fully capable for powertrain as well as body electronics, driver
assistance, and chassis ECU calibration projects.
For vehicle validation, either before or after start-of production, ODX-LINK, the
INCA add-on for ECU diagnostics, can use the ES581.4 to access OBD-on-CAN
functionality as well as to read and clear Diagnostic Trouble Codes (DTCs), effec-
tively eliminating the need for the use of a separate diagnostic service tool.
ES581.4 also provides a J2534 Pass Thru Interface for vehicle diagnostics and
reprogramming with third party applications.
2.4 Interfaces
The front of the ES581.4 Module features a DSUB connector to integrate CAN
interfaces. The back of the module features a cable to connected at the USB port
of a PC.
2.5 Serial Number
The serial number is on the bottom side of the ES581.4.
