4 Source Four Assembly Guide

23 7060A3204 Bolt, 1/4-20 x 1 3/4”, full thread 1

24 HW5123 Nut, hex, 9/16-18, black zinc 1

25 HW534 Nut, hex, 1/4-20, black zinc 1

26 HW746 Screw Retainer Flat 12-6-1 1

27 HW747 Washer, wave 1

28 HW748 Spring, compression CO720-072 1

29 HW749 Spring Ground 1

30 HW8209 Clip, Tinnerman 1

31 W6195 Sleeve, fiberglass 39”, 5/16”, Black 1

32 W689-1 Sleeve, fiberglass 39”, 5/16”, White 1

Note:

Any part that is indicated as “Black” may be also ordered in white or silver. When

ordering white, use the part number suffix -1, and for silver, use the part number

suffix -5.

Reference

Number

Part

Number

Description Quantity

Required
