Operating Instructions
Transponder-Coded Safety Switch CTS-C1-BP/BR-FLX
20
(translation of the original operating instructions) MAN20001587-01-02/23
9.4. Requirements for connecting cables
CAUTION
Risk of damage to equipment or malfunctions as a result of incorrect connecting cables.
Ì Use connection components and connecting cables from EUCHNER.
Ì On the use of other connection components, the requirements in the following table apply. EUCHNER
provides no warranty for safe function in case of failure to comply with these requirements.
Observe the following requirements with respect to the connecting cables:
For safety switches CTS-…-VAB-… with plug connectors 2xM12
Parameter Value Unit
Conductor cross-section, min. 0.25 mm²
R max. 80 W/km
C max. 120 nF/km
L max. 0.65 mH/km
Recommended cable type LIYY 8 x 0.25mm² or 5 x 0.34mm²
For safety switches CTS-…-VSA-… with plug connector M12, 8-pin
Parameter Value Unit
Conductor cross-section, min. 0.25 mm²
R max. 80 W/km
C max. 120 nF/km
L max. 0.65 mH/km
Recommended cable type LIYY 8x0.34mm²
