13.2. Teaching-in new actuator (only for evaluation of the actuator with a high coding level)
Tip!
Prior to switching on the operating voltage, close the guard on which the actuator to be taught-in is
installed. The teach-in operation starts immediately after switching on. This feature simplies above
all teach-in with series connections and on large installations.
Important!
Ì During a teach-in operation, the safety outputs are switched off, i.e. the system is in the safe state.
Ì The safety switch disables the code of the preceding device if teach-in is carried out for a new actuator.
Teach-in is not possible again immediately for this device if a new teach-in operation is carried out.
The disabled code is released again in the safety switch only after a third code has been taught-in.
Ì The safety switch can be operated only with the last actuator taught-in.
Ì The number of teach-in operations is unlimited.
Ì If the actuator to be taught-in is within the actuating range for less than 30s, it will not be activated
and the most recently taught-in actuator will remain saved. The device indicates an error (see chapter
15.3. Error messages on page 37).
Prerequisite:
Ì The device is isolated from the operating voltage.
1. Make sure there is no actuator in the actuating range.
2. Apply operating voltage.
¨ The STATE LED ashes white quickly (5Hz). The device is carrying out a self-test.
¨ The device is in teach-in standby for up to 3 minutes. The STATE LED illuminates white.
3. Insert an actuator that has not been taught-in.
¨ The teach-in operation begins. The STATE LED ashes alternately white/violet slowly.
¨ The teach-in operation ends after approx. 30s. The STATE LED ashes alternately green/blue quickly (approx. 3Hz).
4. Switch off operating voltage for at least 3s.
¨ The code of the new actuator taught-in is activated in the safety switch. The actuator is valid.
5. Switch on operating voltage.
¨ The device operates normally.
