12.3. Overview of the communication data
The switch transmits both process data that are continuously transmitted to the evaluation unit (cyclical data) and data that
can be polled specically as needed (acyclical data). For further information on connection and on the communication data,
refer to the operating instructions for your BR/IO-Link Gateway.
12.3.1. Cyclical data (process data)
Table 2: Cyclical data (process data)
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 1 OI - OER - OM - - OD
Byte 2 - - - - OLS - OL OT
Bit Signal Message
OI Diagnostics There is a fault, see chapter 15.3. Error messages on page 37.
OM Status The safety outputs of the device are switched.
OD Door position1 A valid actuator is detected in the actuating range, and the guard is closed.
OER Escape release The device has been unlocked manually.
OT Door position2 The actuator is inserted in the switch head and the guard locking can be activated.
OLS Locking element
The locking element is stuck, see chapter 15.3. Error messages on page 37.
OL
Guard locking Guard locking is active.
12.3.2. Acyclical data (device data and events)
After one of the commands listed below is sent, the requested data are provided via the IO-Link Gateway. The reply message
always consists of 8 bytes in big endian format.
Example1: Reply message for the command Send device ID number/serial number: 06 02 68 E0 00 01 17 00
In this example, the device’s ID number is 157920 and its serial number is 279.
Byte number Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7
Reply in hex 06 02 68 E0 00 01 17 00
Description
User data length
in bytes
Device ID number Serial number Padding data
Reply in dec. 6 bytes 157920 279 –
Example 2: Reply message for the command Send current device conguration: 02 01 08 00 00 00 00 00
In this example, the device has the high coding level and guard locking monitoring is active.
Byte number Byte 0 Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7
Reply in hex 02 01 08 00 00 00 00 00
Description
User data length
in bytes
Coding level
Guard lock
monitoring
Padding data
Reply in dec. 2 bytes
High coding
level
Active – – – – –
