MAN20001587-01-02/23 (translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTS-C1-BP/BR-FLX
EN
Command Reply
HEX Meaning
Number
of bytes
Bit sequences
(big endian format)
0x02 Send device ID number/serial number 6 Bytes 1-3 Device ID number
Bytes 4-6 Serial number
0x03 Send version number of the device 5 Byte 1 {V}
Bytes 2-4 Version number
0x05 Send number of devices in series connection 1
0x08 Send number of starting processes 3
0x11 Send number of switching cycles (solenoid) 3
0x12 Send current error code 1
0x13 Send most recently saved error code 1
0x14 Send size of log le 1
0x15 Send entry from log le with index 1
0x16 Send current actuator code 5 Bytes 3-5
0x17 Send taught-in actuator code 5 Bytes 3-5
0x18 Send disabled actuator code 5 Bytes 3-5
0x19 Send applied voltage in mV 2
0x0B Send current device conguration 2 Byte 1 0x00 – Coding level not congured
0x01 – High coding level
0x02 – Low coding level
Byte 2 0x00 – Guard lock monitoring not congured
0x04 – Guard lock monitoring inactive
0x07 – Guard lock monitoring active
0x0F Send number of teach-in operations, factory resets and resets for
acknowledging error messages
3 Byte 1 Number of teach-in operations
Byte 2 Number of factory resets
Byte 3 Number of resets for acknowledging error messages
0x1A Send current temperature in °C 1
0x1B Send number of switching cycles 3
0x1D Reset for acknowledging error messages
1)
-
0x1E Factory reset 1 0x1E – Factory reset performed
1) Each BR device must be addressed individually in a chain.
For more information on these and other acyclical data, refer to the operating instructions for your BR/IO-Link Gateway.
