Operating Instructions
Transponder-Coded Safety Switch CTS-C1-BP/BR-FLX
40
(translation of the original operating instructions) MAN20001587-01-02/23
16. Technical data
NOTICE
If a data sheet is available for the product, the information on the data sheet applies.
16.1. Technical data for safety switch CTS-C1-BP/BR-FLX
Parameter
Value
Unit
min. typ. max.
General
Material
- Switch head cover Die-cast zinc
- Safety switch housing Reinforced thermoplastic
Installation orientation Any
Degree of protection IP65/IP67/IP69/IP69K
Safety class acc. to ENIEC61140 III
Degree of contamination (external, acc. to ENIEC60947-1) 3
Mechanical life 1 x 10
6
operating cycles
Ambient temperature
-20 - +55 °C
-20 - +50 °C
Approach speed - - 20 m/min
Actuating force 25 N
Extraction force 25 N
Retention force 10 N
Locking force F
max
3,900 N
Locking force F
Zh
3,000 N
Weight 0.34 kg
Connection (depending on version)
- Connecting cable PVC, 0.14mm, with plug connector M12, 5- and 8-pin
- Connecting cable PVC, 0.14mm, with plug connector M12, 8-pin
- Connecting cable PVC with ying lead, 8 x 0.14mm
Operating voltage U
B
(reverse polarity protected, regulated,
residual ripple < 5%)
24VDC -15% / +20% (SELV) VDC
Current consumption I
UB
50 mA
The following applies to the approval acc. to UL Operation only with UL Class 2 power supply or equivalent measures
Switching load acc. to UL DC 24V, class 2
External fuse (operating voltage U
B
) 1 - 8 A
External fuse (solenoid operating voltage U
IMP
) 1 - 8 A
Rated insulation voltage U
i
32 V
Rated impulse withstand voltage U
imp
0.5 kV
Rated conditional short-circuit current 100 A
Shock and vibration resistance Acc. to EN60947-5-3
EMC protection requirements Acc. to EN60947-5-3
Ready delay
- CTS-…-BP - - 1 s
- CTS-…-BR - - 5 s
Risk time acc. to EN60947-5-3 - - 200 ms
Risk time acc. to EN60947-5-3, extension for each
additional device
10 ms
Turn-on time - - 400 ms
Discrepancy time - - 10 ms
Test pulse duration - - 0.3 ms
Test pulse interval 96 - - ms
