Transponder-Coded Safety Switch CTS-C1-BP/BR-FLX
EN
Parameter
Value
Unit
min. typ. max.
Safety outputs FO1A/FO1B Semiconductor outputs, p-switching, short circuit-proof
Output voltage U
FO1A
/U
FO1B
1)
VDC- HIGH U
FO1A
/U
FO1B
U
B
- 4 - U
B
- LOW U
FO1A
/U
FO1B
0 - 1
Output current
1 - 80 mA
1 - 75 mA
Utilization category
DC-13 24V 80mA
DC-13 24V 75mA
Caution: outputs must be protected with a free-wheeling diode in case of inductive loads.
Switching frequency - - 0.2 Hz
Monitoring outputs Ox/C p-switching, short circuit-proof
Output voltage 0.8 x U
B
- U
B
VDC
Output current
1 - 20 mA
1 - 10 mA
Solenoid
Solenoid operating voltage (reverse polarity protected,
regulated, residual ripple < 5%)
24VDC -15% / +20% (SELV) VDC
Solenoid current consumption I
IMP
500 mA
Connection rating 9 W
Solenoid duty cycle 100 %
Reliability values acc. to ENISO13849-1
2)
Mission time 20 years
Monitoring of guard locking and the guard position
Category 4
Performance Level (PL) e
PFH
D
6.44 x 10
-9
/h
Control of guard locking
Category
Depends on external controlPerformance Level (PL)
PFH
D
Monitoring of the guard position
Category 4
Performance Level (PL) e
PFH
D
6.44 x 10
-9
/h
1) Values at a switching current of 50 mA without taking into account the cable lengths.
2) Refer to the declaration of conformity in chapter 20for the issue date.
