EUCHNER CTS-C1-BP-FLX User Manual

37
MAN20001587-01-02/23 (translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTS-C1-BP/BR-FLX
EN
15.3. Error messages
Error code via IO-Link
LED indicator
Error Troubleshooting
Ac-
knowl-
edging
errors
STATE
RGB
LOCK
orange
DIA
red
Opening/closing door
Reset
Teach-in errors
0x1F
¨
white/red
slowly
Actuator removed from the actuating range prior
to the end of the teach-in operation.
Check whether the actuator is outside the actuat-
ing range or in the limit range.
0x25
blue quickly
Disabled actuator detected during the teach-in
operation:
The actuator was taught-in during the penultimate
teach-in operation and is disabled for the current
teach-in operation.
Repeat the teach-in operation with a new actuator
(see chapter 13.2. Teaching-in new actuator (only
for evaluation of the actuator with a high coding
level) on page 33).
0x42
blue slowly
Invalid actuator detected:
The actuator is not intended for the current device
conguration.
Ì Perform the teach-in operation with an actuator
intended for the current device conguration.
Ì If the device is to be recongured, observe chapter
13.1. Conguring device and teaching-in actuator
for the rst time on page 32.
0x45
blue
Faulty or incompatible actuator detected:
The actuator’s data structure cannot be read. The
actuator is faulty or is not suitable for the device.
Repeat teach-in operation with new actuator.
Input errors
0x2E
violet slowly
Different signal states at the safety inputs FI1A
and FI1B during operation.
Ì Check wiring.
Ì Check preceding device in the switch chain.
0x30
Different signal states at the safety inputs FI1A
and FI1B during the self-test.
0x31
0x32
Test pulses at safety input FI1A or FI1B not detect-
ed during operation.
0x36
0x37
Test pulses at safety input FI1A or FI1B not detect-
ed during self-test.
Output errors
0x54
violet quickly
A HIGH signal is detected at safety output FO1A or
FO1B during the self-test.
Check wiring.
The voltage level at safety outputs FO1A and FO1B
during operation does not meet the requirements.
External voltage might be present.
Transponder/read errors
0x44
blue slowly
Invalid actuator detected during operation:
The actuator is not intended for the current device
conguration.
Use a valid actuator.
0x46
blue
Faulty or incompatible actuator detected during
operation:
The actuator’s data structure cannot be read. The
actuator is faulty or is not suitable for the device.
0x47
blue quickly
Disabled actuator detected during operation:
The actuator is not the currently valid actuator.
0x48
¨
white/blue
slowly
Actuator not taught-in detected during operation. Ì Use the currently valid actuator.
Ì Teach-in actuator.
