Operating Instructions
Transponder-Coded Safety Switch CTS-C1-BP/BR-FLX
44
(translation of the original operating instructions) MAN20001587-01-02/23
16.3. Dimension drawing for safety switch CTS
Necessary minimum travel + perm. overtravel
Approach direction Standard actuator
Horizontal (h) 27 + 4
135
126
5,3
31
18
13,5
7,5
15
34
15,5
31
6,3
126
13,5
15,5
h
LEDs
STATE
LOCK
DIA
LEDs
STATE
LOCK
DIA
78
25
31,5
5
40
11,5
31
15,3
63
Auxiliary release
on the front
Auxiliary release
on the rear
