U2836 Operation Manual Chapter 3 Introduction to [MEAS DISP]
13
800 Hz 8 kHz 80 kHz
DECR-
This is a fine adjustment soft key used to decrease the frequency. The
selectable frequencies are the same as that of INCR+.
DECR--
This is a coarse adjustment soft key used to decrease the frequency. The
selectable frequencies are the same as that of INCR++.
2) Use soft keys or numeric keys to select or set frequency. When using numeric
keys to input the required frequency value, the soft key displays the available
frequency units (Hz and kHz). You can use unit soft key to input unit and data.
When using [ENTER] to input frequency, the default unit is Hz.
3.1.4 Test level
The measurement level of U2836 can be set from 10mV to 2.0V with the
resolution of 10mV.
Operation steps for setting test level:
U2836 provides two methods to set the level of test signal source. The first one is
to use soft keys, while the second one is to input data by numeric keys.
1) Move the cursor to LEVEL
, the following soft keys will be displayed.
INCR+
This soft key is used to increase the level of test signal source.
DECR-
This soft key is used to decrease the level of test signal source.
2) Soft or numeric keys are used to select or set the test level. When numeric
keys are used to input the desired level, the available units (mV, V) will be
displayed in the soft key zone. Users can use these unit keys to input unit and
data.
3.1.5 Test speed
The test speed of U2836 is determined by the following factors:
Integration time (A/D conversion)
Average times (average test times per each test)
Measurement delay (from startup to the start of measurement)
Display time of test results
You can select test mode as FAST, MED or SLOW. Generally, the test result is more
stable and accurate in SLOW test mode.
Operation steps for setting test speed:
1) Move the cursor to SPEED
, the following soft keys will be displayed:
FAST
MED
SLOW
2) Use above soft keys to set the test speed.
