U2836 Operation Manual Chapter 3 Introduction to [MEAS DISP]
20
θº
MORE 4/5
5) Select and press a softkey to set monitor function. If the softkey you need is
not displayed on the page，press More to display the following softkeys.
R
X
G
B
MORE 5/5
3.3.4 Delay time
U2836 trigger delay means the delay time from triggering to test-start. Delay
function can set the trigger delay time. When the list sweep test function is used,
all set delay time will be delayed at each sweep test point. The range of the trigger
delay time can be set from 0s to 60s with 1ms as the resolution. The trigger delay
function is great useful when the instrument is applied in an auto test system.
When the instrument is triggered by HANDLER interface, the trigger delay time
can ensure DUT and test terminal has a reliable contact.
Operation steps for setting the delay function
Execute the following steps to set the measurement delay time.
1) Move the cursor to the DELAY
zone.
3) the following soft keys are displayed.
INCR+
This key is used to increase the trigger delay times.
DECR-
This key is used to decrease the trigger delay times.
4) Use above soft keys to set the delay times or Use numeric keys to input delay
time. After pressing a numeric key, the following unit keys will be displayed.
These soft keys can replace [ENTER] to input delay time.
ms
s
3.3.5 Output impedance
U2836 provides four output impedances for your choice: 100 Ω, 50 Ω and 30 Ω.
When testing inductance, it is necessary to input the same output impedance so
as to make data comparison with other instruments.
Operation steps for setting output impedance
Execute the following operations to set output impedance
1) Move the cursor to the RSOU
zone, the following soft keys will be displayed.
100 Ω
50 Ω
To Next Page
