U2836 Operation Manual Chapter 3 Introduction to [MEAS DISP]
29
3) User numeric keys to input low limit value in Low limit. After inputting the
data, you can use ( m, k, *1) to replace [ENTER] to input the limit value.
After inputting limit value in LOW
of BIN 1, the low limit of BIN 1 will be
automatically set as – (absolute limit) and the high limit will be + (absolute
limit).
4) The cursor will automatically move to LOW
of BIN 2. Repeat step 3 until the
limits of BIN 3 are input. Then the cursor will automatically move LOW
of 2
nd
.
5) After inputting the low limit of the secondary parameter, the cursor will
automatically move to HIGH
of 2
nd
.
6) Input the high limit of the secondary parameter.
7) In Low limit of BIN 1, use numeric keys to input the low limit. After inputting
the data, you can use (p, n, µ, m, k, M, *1) to replace [ENTER] to input the
limit value. When [ENTER] or *1 is used to input the limit value, the default
unit is F, H or Ω.
8) After inputting the low limit of BIN 1, the cursor will automatically move to
HIGH
of BIN 1. Input the high limit of BIN 1.
9) The cursor will automatically move HIGH
of BIN 2. For the limit mode is
sequential mode, the low limit of BIN 2 will be the high limit of BIN 1. Input
the high limit of BIN 2.
10) Repeat step 9 until the high limit of BIN 9 is input. Then the cursor will
automatically move to LOW
of 2
nd
. Input the low limit of the secondary
parameter.
11) The cursor will automatically move to HIGH
of 2
nd
. Input the high limit of the
secondary parameter.
