U2836 Operation Manual Chapter 4 System and FILE
37
5) Press ESC to cancel the current save operation and return step 2.
6) Use numeric keys to input the current file name and press [ENTER]. Then
U2836 will save the control and setting parameters as a file in this name.
B. Load the control and setting parameters from a file by the following
steps
1) Press [FILE], the file list and the following soft keys will be displayed.
LOAD
SAVE
DELETE
COPY
RENAME
EXIT
2) In the file list, move the cursor to the file-saved position or input the file
number directly.
3) Press LOAD, the following soft keys will be displayed.
Yes
No
4) Press No to cancel the current load operation and return step 1.
5) Press Yes to load the currently selected file. Then U2836 will return the
current display page.
C. Copy a file to an U disk by the following steps
1) Assuming that it is necessary to copy internal files 2 and 3 to files 12 and 13
respectively.
2) Press [FILE], the file list and the following soft keys will be displayed.
LOAD
SAVE
DELETE
COPY
RENAME
EXIT
3) Press COPY soft key, the help information display ”Input source file’s No.”
4) Using numeric keys to input the source file’s position, press [ENTER],the help
information display “Input destination file’s No.”
5) Using numeric keys to input the destination file’s position, press [ENTER],the
help information display “Input file’s nums.”
6) Using numeric keys to input the number of files, press [ENTER],the files are
copied to the position.
7) If the input file number is larger than the maximum memory number (100
groups of file setting), the instrument will automatically read and write file in
U-disk automatically. You have to insert a U-disk to the USB interface, UDISK
OK! will be displayed in the file status zone.
———————————————————————————————————————
NOTE: Please make sure that your U-disk meets the standard that described in
this chapter and no write-read protection.
