EVCO S.p.A.
EVBOX1 | Installation guide ver. 2.0 | Code 144BOX1E204
page 64 of 100
PARAM. MIN. MAX. M.U.
EVB1204
EVB1214
EVB1206
EVB1216
EVB1226
EVB1236
EVB1246
EVB1256
DIGITAL INPUTS
i0 0 5 - - - - 3 3 3 3 3 3 3 3
effect caused by the activation of the door micro input;
see also i4 (0 = no effect)
1
=
SWITCH-OFF OF THE COMPRESSOR AND
EVAPORATOR FAN - the compressor and the
evaporator fan will be switched off (at maximum
for time i3 or until the input is deactivated) (31)
2
=
SWITCH-OFF OF THE EVAPORATOR FAN - the
evaporator fan will be switched off (at maximum
for time i3 or until the input is deactivated)
3
=
SWITCH ON OF ROOM LIGHT - the room light
shall be switched on (in the EVB1204 and
EVB1214 models only if u1 = 0; the light shall be
switched off after 10 s from input deactivation)
4
=
SWITCH-OFF OF THE COMPRESSOR AND
EVAPORATOR FAN AND SWITCH ON OF ROOM
LIGHT - the compressor and the evaporator fan
will be switched off (at maximum for time i3 or
until the input is deactivated) and the room light
shall be switched on (in the EVB1204 and
EVB1214 models only if
u1 = 0; the light shall be switched off after 10 s
from input deactivation) (31)
5
=
SWITCH-OFF OF THE EVAPORATOR FAN AND
SWITCH ON OF ROOM LIGHT - the evaporator fan
will be switched off (at maximum for time i3 or
until the input is deactivated) and the room light
shall be switched on (in the EVB1204 and
EVB1214 models only if
u1 = 0; the light shall be switched off after 10 s
from input deactivation)
