EverFocus EDR1640 - Page 13

3
RS-232
9-pin female connector for testing purposes
RS-485
For Keyboard and PTZ connection
Audio
4 mono inputs, 1 mono (SPEAKER) output
Power Source
AC100~240
Power Consumption
60W
Dimension
430 (W) x 88 (H) x 300 (D) mm / 17” (W) x 3.5” (H) x 12” (D)
Weight
6.24 kg (approx. 13.7 lbs)
Operating Temperature
0
o
C ~ +40
o
C / 32℉ ~104℉
Recording Rate
NTSC
PAL
1640 model
D1 720x480 : 120 IPS
Half D1 720x240 : 240 IPS
CIF 360x240 : 480 IPS
D1 720x576 : 100 IPS
Half D1 720x288 : 200 IPS
CIF 360x288 : 400 IPS
1620 model
D1 720x480 : 60 IPS
Half D1 720x240 : 120 IPS
CIF 360x240 : 240 IPS
D1 720x576 : 50 IPS
Half D1 720x288 : 100 IPS
CIF 360x288 : 200 IPS
920 model
D1 720x480 : 60 IPS
Half D1 720x240 : 120 IPS
CIF 360x240 : 240 IPS
D1 720x576 : 50 IPS
Half D1 720x288 : 100 IPS
CIF 360x288 : 200 IPS
