1.2 Specifications
Video Format
NTSC or PAL
Video Input
16 / 9 BNC camera inputs (1Vp-p/75ohm)
1 BNC video out (1Vp-p/75ohm) for Main Monitor
1 S-Video output for Main Monitor
1 BNC video out (1Vp-p/75ohm) for Call Monitor
Video Output
16 / 9 BNC video out (1Vp-p/75ohm) for Looping
Video Compression
MPEG4
EDR1640 Recording
Resolution
720x480 (NTSC:120IPS) / 720x576 (PAL:100IPS)
720x240 (NTSC:240IPS) / 720x288 (PAL:200IPS)
360x240 (NTSC:480IPS) / 360x288 (PAL:400IPS)
EDR1620 Recording
Resolution
720x480 (NTSC: 60 IPS) / 720x576 (PAL: 50IPS)
720x240 (NTSC:120IPS) / 720x288 (PAL:100IPS)
360x240 (NTSC:240IPS) / 360x288 (PAL: 200IPS)
EDR920 Recording
Resolution
720x480 (NTSC: 60 IPS) / 720x576 (PAL: 50IPS)
720x240 (NTSC:120IPS) / 720x288 (PAL:100IPS)
360x240 (NTSC:240IPS) / 360x288 (PAL: 200IPS)
Video Display
Full, 4, 7, 9, 10, 13, and 16 views for Live and Playback
PIP and 2x2 Zoom for Live only
Video Pause
Yes
Alarm Inputs
16/9 Alarm Inputs
Alarm Outputs
4 Alarm Outputs
Hard Disk Storage
Two Hot-Swappable 3.5” IDE Hard Disk
Recording Rate
1640: Up to 480 IPS for NTSC (400 IPS for PAL)
1620/920: Up to 240 IPS for NTSC (200 IPS for PAL)
Recording Mode
Continuous, Schedule, Event (Motion and Alarm) recording
Playback Rate
Up to 60/50 Images per second for NTSC/PAL
Playback Search
By Date/Time or Event (Motion, Video Loss, Alarm)
Motion Detection
Yes, with configurable detection areas & sensitivity
Video Loss Detection
Yes
Event Log
Yes
Setup
Menu Driven On Screen Display
User Input Device
Front panel keypad with Shuttle/Jog Wheel, IR Remote Control,
PS/2 Mouse (optional), EKB500 (optional)
Timer
Built-in real time clock with time synchronization
through NTP Server
Watch Dog Timer
Yes
Title
12-character title for each camera
Ethernet
RJ45 connector for 10/100 Mbps network communication
Archive
USB 2.0 Interface Device for archiving
