evertz TR-4800E - Table 2-10: Rear Panel Outputs 2 (33-48) Connector Pinout

TR-4800E
Tally Router
Page - 12 Revision 1.1
OUTPUTS 3 (33-48)
22
21
23
24
25
13
20
19
18
17
16
15
14
12
11
10
9
8
7
6
5
4
3
2
26
27
28
29
30
31
32
33
34
35
36
37
1
Dry Output 48 (A)
1
20
Dry Output 48 (B)
Dry Output 47 (A)
2
21
Dry Output 47 (B)
Dry Output 46 (A)
3
22
Dry Output 46 (B)
Dry Output 45 (A)
4
23
Dry Output 45 (B)
Dry Output 44 (A)
5
24
Dry Output 44 (B)
Dry Output 43 (A)
6
25
Dry Output 43 (B)
Dry Output 42 (A)
7
26
Dry Output 42 (B)
Dry Output 41 (A)
8
27
Dry Output 41 (B)
Dry Output 40 (A)
9
28
Dry Output 40 (B)
Dry Output 39 (A)
10
29
Dry Output 39 (B)
Dry Output 38 (A)
11
30
Dry Output 38 (B)
Dry Output 37 (A)
12
31
Dry Output 37 (B)
Dry Output 36 (A)
13
32
Dry Output 36 (B)
Dry Output 35 (A)
14
33
Dry Output 35 (B)
Dry Output 34 (A)
15
34
Dry Output 34 (B)
Dry Output 33 (A)
16
35
Dry Output 33 (B)
Wet Voltage Return WET-
17
36
WET+ Voltage (5V/12V/EXT)
Wet Voltage Return WET-
18
37
WET+ Voltage (5V/12V/EXT)
Wet Voltage Return WET-
19
Table 2-10: Rear Panel Outputs 2 (33-48) Connector Pinout
