EVS LSM Connect User Manual

Summary of Shortcut Keys
The table below summarizes the shortcut keys you can use in the toolbar fields.
These are only valid for text and drop-down fields. The shortcuts described above cannot
be used in the Pick keyword dialog box.
To perform the following action ... Use the keyboard shortcut ...
Highlight the next or previous field
(Valid for Name, Type, TC, Icon, Color and Rating
fields)
or
Select the highlighted item (Space)
From the toolbar:
• Display the values list, when a drop-down field
is highlighted.
• Open a secondary window with a values list.
From a secondary window:
• Select the highlighted item and close the
window.
From a secondary window:
Close the window without saving the changes
From the toolbar, open a dialog box to assign a
name to the clip or modify the current name.
How to Assign or Modify a Clip Name with the
Touchscreen
To assign/modify the name of one or more clips with the touchscreen, proceed as follows:
1. In the clip tab, tap the clip(s) whose name you want to assign or modify.
2. In the clip toolbar, tap the Name field.
The virtual keyboard appears.
3. Type the requested name in the virtual keyboard.
4. Click Next on the keyboard.
The name is applied to the selected clip(s).
How to Assign or Modify a Clip Name with a Keyboard
NOTE
To be able to load clips and playlists in LSM Connect, enable the Load
clip/playlist option in the LSMConnect settings (see section "Server
Parameters" on page 101).
42 3. Clip Management
EVS Broadcast Equipment SA Issue 2.12.D- April 2020
