Color and Density (D)
To set the drawing color and the line thickness, proceed as follows:
1. Select D on the Paint mode monitor display.
2. Select the desired color from the display.
3. Select the desired line thickness.
4. These settings are stored as Br1 or Br2 depending on which one was selected when
entering the D option. Thus, two differetn settings can be stored.
Erase (E)
To use the pen as an eraser, proceed as follows:
1. Select E on the Paint mode monitor display.
2. Use the pen as an eraser.
3. This option remains «on» until you select E again to turn it off and return to the
previous active drawing mode.
Clear (C)
To clear a drawing, proceed as follows:
1. Select C on the Paint mode monitor display.
2. Choose between the 3 following options:
◦ Clr to clear all drawings.
◦ DfC to define customized colors.
◦ ESC to exit this function without clearing any drawing.
If you select Define Colour (DfC), a new screen will appear including a U-V selection area,
and an Y level selection area. Select first the color you want to edit on the top of the
screen, then select the U-V and Y values by moving the pen on the right location of each
selection area. When the adjustment is made, move the pen to an empty zone of the
screen.
The CLEAR function is also available from the Remote Panel (SHIFT+B).
Warning
No confirmation is required.
OPERATION MANUAL Multicam LSM 12.05
9. Advanced Control Modes 185
