Excell SI-132 - Baud Rate Setting

EXCELL PRECISION CO., LTD
SI-132 v1.1 SME300000081
23
2-5-1 Baud Rate Setting
Select in the RS232 serial interface setting mode
to set the Baud Rate.
Baud rate setting
LCD displays the last value
4 Default value: 9600 (bits/sec)
Baud rate setting
Use ON/ZERO or UNITS keys to select the
desired Baud rate 600、1200、2400、
4800、9600、19200、38400 (bits/sec)
Press TARE key
Use ON/ZERO or UNITS
key to select the desired
Baud rate
Press TARE key
Key in the parameter “00”
Press the TARE key to
exit RS232 serial interface
settings
ON/ZERO key
⇒
Upward key (from 0 to 9)
UNITS key ⇒ Downward key (from 9 to 0)
TARE key ⇒ Move the cursor to right
NET/GROSS key ⇒ Move the cursor to left.
ACTIONS
DISPLAY
NOTE
