they tend to generate.
Parameter 1 sets the length of the shift register, and so the length of the repeating CV pattern in
terms of clocks.
Parameter 2 sets the output slew rate. This has the same effect as the Slew Rate Limiter algorithm
being applied to the outputs.
Parameter 3 is an attenuverter for both outputs.
Parameter 4 is an offset for both outputs.
MIDI Input: if parameter 5 is non-zero, incoming MIDI clock advances the shift register,
according to the following table:
Parameter value Clock divisor Parameter value Clock divisor
1 1/32 9 1/4
2 1/16 triplet 10 1/2 triplet
3 1/16 11 3/8
4 1/8 triplet 12 1/2
5 3/32 13 1/1 triplet
6 1/8 14 3/4
7 1/4 triplet 15 1/1
8 3/16
F-6 Shift Register Random Quantized CVs
Page 55
