Extec E-7 - Technical Data

J-1160
R
Jaw Crusher
EXTEC E 7 (QE 340) SCALPER SCREEN
Key specifications
Equipment
-
Max feed size
600
Capacity up to
350 MPTH
No. of products
3
Weight (tons)
31.8 t
Operating dimensions
Height
4.25m (13’ 11”)
Width
12.96m (42’ 6”)
Length
14.41m (47’ 3”)
Transpor
t dimensions
Height
3.44m (11’ 3”)
Width
3.15m (10’ 4”)
Length
13.95m (45’ 9”)
Main conveyor dimensions
Height
3.10m (10’ 2”)
Width
1.20m (3’ 11”)
Side conveyor dimensions
Height
3.00m (9’ 10”)
Width
0.80m (2’ 7”)
© Sandvik Mining and C
onstruction Internet
Latest update: 22.06.2009
The EXTEC E
–
7 track mounted scalping screen is a self propelled, revolutionary plant
designed for the
recycling and quarry markets.
The E
–
7 is an excellent solution for applications such as:
Screening hea
vy overburden at the quarry face,
Pre
–
Screening/scalping ahead of a crusher
Recycling construction and landfill waste
Separation of top soil or coarse clay filled deposits
Equipped as follows:
Heavy duty screen box with a unique high throw and vibration
Ad
justable angle of incline ranging from 10
–
22 degrees
5' x 15'3" Top Deck, Finger Grizzly
5' x 14' Bottom deck, Harp Screen
Heavy duty hopper with hydraulic folding wing walls
Feed Hopper hydraulic slides into operation position
Page 1 of 2
42" x 13' Heavy
duty double plated Apron Feeder
Large free flow area from the hopper onto screen box
48" x 18' Top Deck Front Discharge Slider Bed Conveyor, with chevron belt to prevent roll
back
30" x 24' Second Deck Side Conveyor, Discharge Height of 10'11"
Under Screen
Collecting Conveyor, 48" x 15'
Deutz BF4M2012
–
74.9 KW(100.4 HP) water cooled engine
77 gallon fuel tank
98 gallon hydraulic tank
Heavy duty crusher type chassis
Working height 13'11
Working length 47'3"
Deutz 2012 turbocharged engine, 100.4hp
