Section 1
General
Pilot´s Operating Handbook
EXTRA 300L
1.3.2 MAIN DATA
- Length 6,96 m (22,83 ft)
- Height 2,62 m ( 8,60 ft)
- Span 8,00 m (26,25 ft)
- Wheel-base 5,07 m (16,63 ft)
- Wheel-track 1,80 m ( 5,91 ft)
1.3.3 WING
- Wing span 8,0 m (26,25 ft)
- Wing-area 10,7 m² (115,17 ft²)
- Airfoil Root: MA 15 S. Tip, MA 12 S
- Chord Root: 1,85 m. Tip, 0,88 m
- MAC 1,404 m ( 4,61 ft)
- Aileron area 2 x 0,855 m² (2 x 9,20 ft²)
- Aileron deflection up/down 30°, tolerance ± 2°
1.3.4 HORIZONTAL TAIL
- Span 3,20 m (10,50 ft)
- Area 2,56 m² (27.56 ft²)
- Airfoil Wortmann FX 71-L-150/30
1.3.5 ELEVATOR
- Area 0,77 m² (8,29 ft²)
- Elevator-deflection up/down 25°, tolerance ±2°
- Trim-tab-deflection up 40°, down 50°, tolerance ±5°
1.3.6 VERTICAL TAIL
- Area 1,39 m² (14,96 ft²)
- Airfoil Wortmann FX 71-L-150/30
1.3.7 RUDDER
- Area 0,51 m² ( 5,49 ft²)
- Rudder deflection left/right 30°, tolerance ±2°
