7 - 6 Page Date: 20. April 2002
Section 7
Description and Operation of Aircraft and Systems
PilotĀ“s Operating Handbook
EXTRA 300L
7.6 INSTRUMENTATION
The Extra 300/L is equipped with flight instruments in both cockpits.
Instruments and placards can be provided with markings in either metric or English units. The
colour markings in instruments follow US-FAR, part 23 recommendation ( see section 2 ).
7.6.1 INSTRUMENT PANEL (REAR COCKPIT)
For instrument panel arrangement of the rear cockpit refer to Fig. 7.6.1, which includes
standard and optional equipment marked as such.
Fig. 7.6.1:
1 2 3 4 5 6
15 14 13 12 11 10 9 8 7
