Extra 300L - Weight and Balance

Section 922
Center Tank Increased Capacity
Page Date: 5. December 2008 922 - 7
Pilot´s Operating Handbook
EXTRA 300L
922.6 WEIGHT AND BALANCE
LOADING WEIGHTS AND MOMENTS
TOTAL FUEL CAPACITY: 189 L (49.9 US gal)
FUEL
ACRO & CENTER TANK WING TANK
L kg kg x cm L kg kg x cm
(US gal) (lb) (lb x in) (US gal) (lb) (lb x in)
9 (2.4) 6.5 (14.3) 182 (157) 10 (2.6) 7.2 (15.9) 360 (313)
20 (5.3) 14.4 (31.8) 420 (365) 20 (5.3) 14.4 (31.8) 721 (629)
25 (6.6) 18.0 (39.7) 529 (459) 40 (10.6) 28.8 (63.5) 1442 (1257)
30 (7.9) 21.6 (47.6) 638 (553) 60 (15.9) 43.2 (95.3) 2164 (1886)
35 (9.2) 25.2 (55.6) 746 (648) 80 (21.1) 57.6 (127.0) 2885 (2514)
40 (10.6) 28.8 (63.5) 855 (742) 100 (26.4) 72.0 (158.8) 3607 (3144)
45 (11.9) 32.4 (71.4) 964 (836) 120 (31.7) 86.4 (190.5) 4328 (3771)
50 (13.2) 36.0 (79.3) 1073 (931)
55 (14.5) 39.6 (87.3) 1182 (1026)
60 (15.9) 43.2 (95.2) 1290 (1120)
65 (17.2) 46.8 (103.2) 1399 (1215)
69 (18.2) 49.7 (109.6) 1487 (1291)
