Section 909
Smoke System
Page Date: 20. April 2002 909 - 5
PilotĀ“s Operating Handbook
EXTRA 300L
yticapaCssaMtnemoM
ertiLlagSUgKsblmcgKsbl-ni
53.13.44.9911301
017.25.87.81412681
514 8.211.82763913
023.5715.73594034
526.63.129.64226145
132.
84.622.85577476
After automatic refill shut-off :
3. Switch "SMOKE REFILL" OFF
4. Refill hose DISCONNECT
N O T E
A shut-off failure of the refill process can be recognized by smoke oil spilling out of
the vent line. In this case, turn off refill switch. The floating device switch in the main
smoke oil tank has to be checked accordingly.
B) SMOKE GENERATION
1. Bad weather window and ventilation CLOSE
2. "SMOKE ARM" Switch ON
3. Manifold Pressure minimum 20" Hg
4. Switch in the throttle lever
for smoke generation ON - OFF
C A U T I O N
Smoke might enter the cockpit via the air vents during reverse maneuvers (for
example tail slide).
It is recommended to operate the smoke system only in forward flight.
909.5 PERFORMANCE
Not affected.
909.6 WEIGHT AND BALANCE
Specific Weight of the paraffin oil = 0.85 kg/Litre
N O T E
The smoke system does not feature a capacity dipstick. In the case of unknown
filling, the smoke oil tanks should be drained and refilled with a known quantity. If
this is not possible, the most adverse case has to be taken for CG calculation. (This
may be either completely full or completely empty tanks).
Page Date: 20. January 2016
