Extra 300L - Instrument Markings

2 - 12 Page Date: 20. April 2002
Pilot´s Operating Handbook
EXTRA 300L
Section 2
Limitations
2.14.3 INSTRUMENT MARKINGS
AIRSPEED INDICATOR
green arc 60 KIAS (111 km/h) - 158 KIAS (293 km/h)
yellow arc 158 KIAS (293 km/h) - 220 KIAS (407 km/h)
red line 220 KIAS (407 km/h)
OIL PRESSURE INDICATOR
Range markings are depending on instrument installed.
red line 25 Psi
yellow arc 25 Psi - 55 Psi
green arc 55 Psi - 90 Psi or 55 Psi - 95 Psi
yellow arc 90 Psi - 100 Psi or 95 Psi - 115 Psi
red line 100 Psi or 115 Psi
OIL TEMPERATURE INDICATOR
yellow arc < 140 °F
green arc 140 °F - 210 °F
yellow arc 210 °F - 245 °F
red line 245°F
CYLINDERHEAD TEMPERATURE INDICATOR
yellow arc < 150 °F
green arc 150 °F - 435 °F
yellow arc 435 °F - 500 °F
red line 500°F
RPM INDICATOR
green arc 700 RPM - 2400 RPM
yellow arc* 2400 RPM - 2700 RPM
red line 2700 RPM
G - METER
green arc - 5 g - + 8 g
yellow arc + 8 g - + 10 g
red line + 10 g
FUEL FLOW INDICATOR
green arc 0 gal / h - 35 gal / h
red radial 35 gal / h
*) Refer to Section 4.6 and 4.8.2
