Extra 300L - Sample; Weight and Balance Record Sheet

Page Date: 20. April 2002 6 - 7
Section 6
Weight and Balance and Equipment List
Pilot´s Operating Handbook
EXTRA 300L
6.3.1 Sample
Take-off Condition:
Pilot On Rear Seat 90.0 kg ( 198.5 lbs)
Copilot On Front Seat 90.0 kg ( 198.5 lbs)
Acro Fuel 51 L 37.0 kg ( 81.5 lbs)
101 L Fuel In Wing Tanks 73.0 kg ( 160.9 lbs)
Aircraft Empty Weight 660.0 kg (1455 lbs)
======== ==========
950.0 kg (2094.4 lbs)
To find C/G, follow line "Pilot Rear Seat" from Empty Weight to "90 kg" [198.5 lbs] (Point 1).
Continue on line "Copilot Front Seat" to 90 kg (Point 7). Now follow line "Fuel" via Point 8
(51 L [13.5 US.gal] Acro Fuel) to Point 9 (101 L [26.6 US.gal] Fuel in Wing Tank).
FIND: Weight ~ 950 kg (2094.4 lbs)
C/G ~ 75.4 cm (29.6 inch)
6.3.2 Weight and Balance Record Sheet
WEIGHT ARM MOMENT
EMPTY WEIGHT
PILOT
COPILOT
ACRO FUEL
WING FUEL
ΣΣ
ΣΣ
Σ W =
ΣΣ
ΣΣ
Σ ( W x X ) =
XG = =
Σ Σ
Σ Σ
Σ ( W x X )
ΣΣ
ΣΣ
Σ W
