Section 907
Long Range Wing Tank Capacity
Page Date: 20. April 2002 907 - 3
PilotĀ“s Operating Handbook
EXTRA 300L
907 LONG RANGE WING TANK CAPACITY
907.1 GENERAL
The leading edge wing tank on the EA 300/L equipped with the long range tank capacity
features two tank compartments on either wing side. The compartments are separated by a
slosh rib.
907.2 LIMITATIONS
FUEL
Minimum grade aviation gasoline: 100/100LL;
for alternate fuelgrades see latest revision of Lyc. S.I. No. 1070
Total fuel capacity: 205 L (54.1 US Gallons).
- Wingtank: 154 L (2 x 77 L) (40.7 US Gallons)
- Acro & Center Tank: 51 L (13.4 US Gallons)
Usable fuel capacity in the system: 199.5 L (52.7 US Gallons).
For acrobatic flight wing tanks must be empty.
Usable fuel capacity for acrobatic: 45.5 L (12.0 US Gallons).
WEIGHT LIMITS
Max. allowed empty weight - Normal category: 716 kg (1578lbs)
PLACARD
The existing FUEL SELECTOR VALVE - placard has to be replaced by the following placard:
(in both cockpits
near selector valve handle)
907.3 EMERGENCY PROCEDURES
Not affected.
907.4 NORMAL PROCEDURES
Not affected
FUEL SELECTOR VALVE
CENTER +
ACRO
TANK
usable 45,5 L
(12,0 US GAL)
OFF
WING TANKS
usable 154 L(40,7 US GAL)
