920 - 8 Page Date: 31. March 2009
PilotĀ“s Operating Handbook
EXTRA 300L
Section 920
BECKER BXP 6401 Transponder
SETTING THE FLIGHT NUMBER:
1 Press SEL button (G) to enter the select mode.
2 Rotate (B) until 'AI' is displayed.
3 Push (C) to switch to 'FN'. The cursor is set on the first character.
4 Rotate (B) to change this character.
5 Push (C) to set the cursor to the next character.
6 Repeat steps 4 and 5 until the flight number is entered.
7 If the flight number consists of less than 7 characters, put a space at the end to fill the remaining
characters with spaces.
8 Store the changes with STO button (F). For leaving the setting procedure without storing, push
the SEL button (G).
N O T E
Aircraft Identifier / Flight Number consists of max. 7 characters (on the left- hand side
oriented). No dashes or spaces shall be included. If the FN con- sists of less than 7
characters, the remaining characters on the right side shall be filled with spaces.
SWITCHING BACK TO DEFAULT AI:
1 Press SEL button (G) to enter the select mode.
2 Rotate (B) to the indication 'FN=XXXXXXXX'.
3 First push on (C) indicates'FN=AI DEF' (inverted).
4 Can be set to 'AI=DEF' with STO button (F).
CHANGING THE FLIGHT NUMBER:
1 Press SEL button (G).
2 Rotate (B) until 'FN' is displayed.
3 Push (C) twice to enter the FN editing mode.
4 Change the FN as described above.
