Page Date: 5. December 2008 921 - 15
PilotĀ“s Operating Handbook
EXTRA 300L
Section 921
Lycoming AEIO-580-B1A Engine
Figure 921-1 shows both fuselage fuel tank configurations which are available for the EXTRA 300L
ex factory. Item 6 shows the contour of the center tank with 42 L (11.1 US gal) capacity
(configuration 1). Item 7 shows the contour of the center tank with 60 L (15.9 US gal) capacity
(configuration 2). In each configuration the center tanks are located above the acro tank (1) having
9 L (2.4 US gal) fuel quantity. They are installed in the same place and in the same manner. This
includes the vent line (2) and the fuel filler (5) location. However the steel tubes of the fuselage
carrying the 60 L tank and its mounting have been reinforced. The configuration 1 fuel quantity probe
(3) is located in front of the fuel filler (5), the configuration 2 probe (4) is located behind. The fuel
quantity indicators are identical in both configurations.
Page Date: 19. April 2012
