Page Date: 20. April 2002 6 - 11
Section 6
Weight and Balance and Equipment List
PilotĀ“s Operating Handbook
EXTRA 300L
1 Throttle Control Teleflex F303 03250 0.56 0.60 R
or CC330 10'
1 Throttle Control Cable Cablecraft 580-540-501 0.63 0.60 A
1 Propeller MT-Propeller MTV-9-B-C/C200-15 30.40 -1.15 R
1 Spinner MT-Propeller P-208-B 0.8 -1.20 R
1 Spinner MT-Propeller P-810-2 0.8 -1.20 A
1 Propeller MT-Propeller MTV-14-B-C/C190-17 29.80 -1.15 O
1 Spinner MT-Propeller P-238-A 0.8 -1.20 O
1 Spinner MT-Propeller P-967 0.8 -1.20 A
1 Propeller MT-Propeller MTV-9-B-C/C198-25 30.50 -1.15 O
1 Spinner MT-Propeller P-810-2 0.8 -1.20 O
1 Cowling (GRP) EXTRA 23205.01 & .02 9.80 -0.52 R
EXTRA 83802.1
1 Cowling (CRP) EXTRA 23205.301 & .302 8.80 -0.52 A
EXTRA 83802.1
1 Cowling (CRP) EXTRA 83001.0 9.20 -0.57 A
1 Cowling (GRP) EXTRA 83003.0 10.60 -0.57 A
1 Cowling (CRP) EXTRA 8E001.0 9.20 -0.57 A
(incl. Landing Light
provision)
1 Governor Woodward A- 210 988 1.10 -0.91 R
1 Governor MT-Propeller P-880-5 1.10 -0.91 A
1 Governor MT-Propeller P-880-41 1.10 -0.91 A
7 Switches Cutler Hammer div. 0.28 1.63 R
7 Switches Kissling div. 0.28 1.63 A
11 Circuit Breaker Potter&Brumfield div. 0.50 1.60 R
11 Circuit Breaker ETA or Klixon div. 0.30 1.60 A
1 Main Bus Fuseholder MTA 03.00360 0.03 0.02 O
1 Main Bus Strip Fuse MTA 02.00300 O
(40 Amps)
1 PCB Auto Fuse EXTRA 83290.1 0.01 0.03 O
1 Fuel Cont. Probe VDO 226 801 015 001 G 0.12 0.49 R
Wing Tank
1 Fuel Cont. Probe VDO 224 082 006 097 R 0.20 0.20 R
Center Tank 42 L or 224-011-010-251
1 Fuel Cont. Probe VDO 224 082 007 004 R 0.20 0.44 A
Center Tank 60 L or 224-011-020-372
1 Fuel Cont. Ind. VDO 301 271 036 001 K 0.08 1.62 R
Wing Tank or 301 030 001 G
1 Fuel Cont. Ind. VDO 301 272 052 001 K 0.14 1.62 R
Acro Tank or 301 030 002 G
1 Ammeter VDO 190 004 039 002 0.08 1.62 R
or 190 037 002 G
1 Volt/Ammeter Electronics Intern. VA-1A 0.26 1.62 A
1 Shunt Electronics Intern. S-50 0.09 1.50 A
1 Volt/Ammeter Electronics Intern. VA-1A-50 0.22 1.62 A
1 RPM Indicator VDO 333 230 115 002 0.31 1.60 R
or 333 035 001 G
1 RPM Indicator digital Horizon P100-230-643-00 0.68 1.60 A
(2700RPM)
QTY ITEM MANUFACT. PART OR P/N WEIGHT ARM MARK IF REQUIRED (R)
(kg) (m) INSTALLED OPTIONAL (O)
ALTERNAT. (A)
Page Date: 20. January 2016
