600 W AC PoE Power Supply Technical Specifications
The 600 W AC PoE power supply (Model XN-ACPWR-600W with front-to-back ventilation airflow) is
compatible with 5420F-24P-4XE and 5420F-8W-16P-4XE switch models.
600 W AC PoE Power Supply (XN-ACPWR-600W)
Table 46: Physical Specifications
Dimensions Height: 1.57 inches (3.98 cm)
Width: 2.87 inches (7.3 cm)
Length: 7.28 inches (18.5 cm)
Weight 1.87 lb (0.85 kg)
Table 47: Power Specifications
Voltage input range
100-127/200-240 47 to 63Hz
Nominal input ratings 12.5 A max at 115VAC and 6A max at 230VAC at Full 350 W load
Maximum inrush current 45A at Max 264 VAC at 25C with cold start
Output 54 V, 13.2 A max, 350 W
Power supply input socket and cord IEC/EN 60320 C14 AC input receptacles
Power cord wall plug Refer to Power Cord Requirements for AC-Powered Switches
and AC Power Supplies on page 110
Eciency Minimum eciency: 88% at maximum power output
Table 48: Environmental Specifications
Operating temperature 0°C to 50°C (normal operation)
Storage temperature -40°C to 70°C
Operating humidity 93% relative humidity, non-condensing at 30C
Operational shock 30 m/s
2
(3 G)
920 W AC PoE Power Supply Technical Specifications
The 920 W AC PoE power supply (Model XN-ACPWR-920W with front-to-back ventilation airflow) is
compatible with 5420F-48P-4XE, 5420F-48P-4XL, 5420M-24W-4YE, 5420M-48W-4YE,
5420M-16MW-32P-4YE switch models.
Technical
Specifications 600 W AC PoE Power Supply Technical Specifications
ExtremeSwitching 5420 Series Hardware Installation Guide 107
