Extreme Networks ExtremeSwitching 5420 Series - 1200 W AC PoE Power Supply; 2000 W AC PoE Power Supply

The 1200 W AC PoE power supply has a keyed power inlet (C16) that requires a notched (C15) power
cord.
The 1200 W AC PoE power supply has the status LEDs listed in the following table:
Table 7: 1200 W AC PoE Power Supply LED Status Indications
DC_OK
(left)
AC_OK (right) Description
Green/1H
z flashing
Green AC present / only standby outputs on.
Green Green Power supply DC outputs on and OK.
Red Green Power supply failure. PSU shut down*.
*Power supply DC fail : OCP, OVP, OTP, fan.
2000 W AC PoE Power Supply
The 2000 W AC PoE power supply (Model XN-ACPWR-2000W with front-to-back ventilation airflow)
is compatible with 5420M-48W-4YE and 5420M-16MW-32P-4YE switch models.
In order to obtain 2000W output from this power supply, the PSU must be connected to a 200-240VAC
source.
The 2000 W AC PoE power supply has a keyed power inlet (C16) that requires a notched (C15) power
cord.
The 2000 W AC PoE power supply has the status LEDs listed in the following table:
Table 8: 2000 W AC PoE Power Supply LED Status Indications
DC_OK
(left)
AC_OK (right) Description
Green/1H
z flashing
Green AC present / only standby outputs on.
Green Green Power supply DC outputs on and OK.
Red Green Power supply failure. PSU shut down*.
*Power supply DC fail : OCP, OVP, UVP, OTP, fan.
Power Supplies for Use with Your Switch
2000 W AC PoE Power Supply
ExtremeSwitching 5420 Series Hardware Installation Guide 33
