Table 42: Environmental Data (continued)
Operational shock (half sine): 30 m/s
2
(3 G), 11 ms, 60 shocks
Operational random vibration: 3 to 500 Hz at 1.5 G rms
Storage & transportation
conditions (packaged)
Transportation temperature: -40°C to 70°C (-40°F to 158°F)
Storage and transportation humidity: 10% to 95% relative humidity,
non-condensing
Packaged shock (half sine): 180 m/s
2
(18 G), 6 ms, 600 shocks
Packaged sine vibration: 5 to 62 Hz at velocity 5 mm/s,
62 to 500 Hz at 0.2 G
Packaged random vibration: 5 to 20 Hz at 1.0 ASD w/–3 dB/oct.
from 20 to 200 Hz
14 drops minimum on sides and corners at 42 inches (<15 kg box)
150 W AC Power Supply Technical Specifications
The 150 W AC power supply (Model XN-ACPWR-150W with front-to-back ventilation airflow) is
compatible with 5420F-24T-4XE, 5420F-24S-4XE, 5420F-48T-4XE, 5420M-24T-4YE, and
5420M-48T-4YE switch models.
150 W AC Power Supply (XN-ACPWR-150W)
Table 43: Physical Specifications
Dimensions Height: 1.54 inches (3.9 cm)
Width: 2.89 inches (7.35 cm)
Length: 7.28 inches (18.5 cm)
Weight 1.63 lb (0.74 kg)
Table 44: Power Specifications
Voltage input range
100-127/200-240 47 to 63Hz
Nominal input ratings 12.5 A max at 115VAC and 6A max at 230VAC at Full 350 W load
Maximum inrush current 45A at Max 264 VAC at 25C with cold start
Output 54 V, 13.2 A max, 350 W
Power supply input socket and cord IEC/EN 60320 C14 AC input receptacles
Power cord wall plug Refer to Power Cord Requirements for AC-Powered Switches
and AC Power Supplies on page 110
Eciency Minimum eciency: 88% at maximum power output
Table 45: Environmental Specifications
Operating temperature 0°C to 50°C (normal operation)
Storage temperature -40°C to 70°C
Operating humidity 93% relative humidity, non-condensing at 30C
Operational shock 30 m/s
2
(3 G)
150 W AC Power Supply Technical Specifications Technical Specifications
106 ExtremeSwitching 5420 Series Hardware Installation Guide
