In addition to statistics and recommendations, colors in the display show whether the selected switch
models and stacking methods are compatible.
Table 17: Colors in the Stacking Tool Display
Color Meaning
Green Compatible and preferred
Blue Compatible
Yellow Incompatible with the selected primary node
Red Incompatible
Setting up the Physical Stack
After you have installed the individual switches (see "Installing Your Switch"), follow these steps to
create the physical stack.
1. Connect the switches that will form the stack.
See Connecting the Switches to Form the Stack Ring on page 66.
2. Connect stacking cables to the switches.
See Connecting Stacking Cables on page 71.
3. Connect the switches to your management network.
See Connecting Your Stack to the Management Network on page 73.
After setting up and connecting the switches, perform software configuration for the stack. See
"Configuring a New Stack" in the ExtremeXOS 31.3 User Guide.
Connecting the Switches to Form the Stack Ring
After you have installed the individual switches, connect them together using the stacking cables.
The examples in this section show cable connections and the recommended order for connecting ports
to facilitate the easy setup configuration.
In general, it is best to connect Stack Port 2 on one switch to Stack Port 1 on the switch with the next
higher slot number. Although you can connect the switches in any order, connecting them as shown in
these examples will produce better predictability and easier software configuration.
All connections between stack ports must be directly between switches. A stacking connection cannot
pass through a third device, for example a Virtual Port Extender or an LRM/MACsec Adapter.
It is essential to create an unbroken data path through all the switches in the stack.
For instructions to connect specific types of stacking cables, see Connecting Stacking Cables on page
71.
Combining Dierent Types of Stacking Ports
Figure 40 shows an example stack configuration using the following switches: X440-G2, X450-G2,
X460-G2, and X620.
Setting up the Physical Stack
Building Stacks
66 ExtremeSwitching 5420 Series Hardware Installation Guide
