715 W AC Power Supplies
The 715 W AC PSU-FB (models XN-ACPWR-715W-FB and 10951 with front-to-back
ventilation airow) are compatible with VSP4900-48P and VSP4900-12MXU-12XE switch
models that have the same airow direction as the power supply.
The 715 W AC power supply has a keyed power inlet (C16) that requires a notched (C15)
power cord.
The 715 W AC power supply has the status LEDs listed in the following table:
Table 5: 715 W AC Power Supply LED Status Indications
IN_OK
(Green)
OUT_OK
(Green or
Red)
Description
Off Off No AC input power connection or low AC voltage.
On Off AC input good, 54V output disabled.
On (Red) On AC input good, output (54V) fault.
On (Green) On AC input good, DC outputs in spec.
1100 W AC Power Supplies
The 1100 W AC PSU-FB (models XN-ACPWR-1100W-FB and 10941 with front-to-back
ventilation airow) is compatible with VSP4900-48P and VSP4900-12MXU-12XE switch
models that have the same airow direction as the power supply.
The 1100 W AC power supply has a keyed power inlet (C16) that requires a notched (C15)
power cord.
The 1100 W AC power supply has the status LEDs listed in the following table:
Table 6: 1100 W AC Power Supply LED Status Indications
IN_OK
(Green)
OUT_OK
(Green or
Red)
Description
Off Off No AC input power connection or low AC voltage.
On Off AC input good, 54V output disabled.
On (Red) On AC input good, output (54V) fault.
On (Green) On AC input good, DC outputs in spec.
2000 W AC Power Supply
The 2000 W AC PSU-FB (models XN-ACPWR-2000W-FB and XN-ACPWR-2000W-
F with front-to-back ventilation airow) are compatible with VSP4900-48P and
715 W AC Power Supplies Power Supplies for Use with Your Switch
18 VSP 4900 Series Switches: Hardware Installation Guide
