Figure 14: VIM5-4YE Versatile Interface Module
Table 14: Port Numbers for Ports on the VIM5-4YE Module
ExtremeSwitching VSP 4900
port number for VSP4900-24S
ExtremeSwitching VSP 4900
port numbers for VSP4900-48P, 24XE,
and 12MXU-12XE models
2/1 2/1, 2/2
VIM5-2Q Versatile Interface Module
The VIM5-2Q versatile interface module provides two 40-GbE (QSFP) ports.
Note
For VSP4900-48P and VSP4900-24S, only the rst 40-GbE (QSFP) port is
supported.
For information about the supported optical modules, refer to the most recent version
of the Extreme Hardware/Software Compatibility and Recommendation Matrices .
Expansion Modules VIM5-2Q Versatile Interface Module
VSP 4900 Series Switches: Hardware Installation Guide 27
