Figure 15: VIM5-2Q Versatile Interface Module
Table 15: Port Numbers for Ports on the VIM5-2Q Module
ExtremeSwitching VSP 4900
port numbers for 24-port models
ExtremeSwitching VSP 4900
port numbers for 48-port models
2/1 in 1x40 mode
2/1, 2/2, 2/3, 2/4 in 4x10 mode
2/1 in 1x40 mode
2/1, 2/2, 2/3, 2/4 in 4x10 mode
Solid-state Drives
Solid-state Drives (SSD) provide modular storage support. VSP 4900 Series switches
accommodate one SSD module using a reserved slot on the rear of the switch, which is
supported on VOSS release 8.1.5 and later.
The following SSD module is available for VSP 4900 switches:
Table 16: Available SSD Module
SSD Module Description Compatible Switch Models
XN-SSD-001-120 Modular 120GB SSD VSP4900 (all models)
Solid-state Drives Expansion Modules
28 VSP 4900 Series Switches: Hardware Installation Guide
