DXP HD 4K PLUS Series • Operation 17
• Secondary:
• Save and recall presets (see Saving and Recalling Presets on page25).
• Mute video and audio output (see Muting and Unmuting Outputs from the
Front Panel on page87).
• De-embed HDMI audio signals from the input.
DXP 42
• Primary: Select an output.
• Secondary: View ties.
D
Control buttons — (DXP 44, 84, and 88 only) The three Control buttons have the
following functions:
• Enter button — The Enter button has the following functions:
Primary:
• Save changes made on the front panel.
• Indicate that a potential tie has been created but not saved.
• Indicate that a preset has been selected to be saved or recalled but the preset
action has not been completed.
Secondary:
• Select 9600 baud rate for the Remote RS-232 port.
• Set the front panel lock mode (executive mode).
• In conjunction with the Preset and Esc buttons, place the switcher in serial
port configuration mode.
• Indicate that the Remote RS-232 port is set to 9600 baud in serial port
configuration mode (blinking).
• Preset button — (DXP 44, 84, and 88 only) The Preset button has the following
functions:
Primary:
• Place the switcher in preset saving mode to save a configuration as a preset,
and in preset recalling mode to activate a previously-defined preset.
• Indicate when preset saving mode is active (blinks) and when preset recalling
mode is active (lights steadily).
Secondary:
• Select the 19200 baud rate for the Remote RS-232 port.
• In conjunction with the Enter and Esc buttons, place the switcher in serial port
configuration mode.
• Indicate that the Remote RS-232 port is set to 19200 baud in serial port
configuration mode (blinking).
• Esc button — (DXP 44, 84, and 88 only) The Esc button does the following:
Primary:
• Cancel operations or selections in progress and resets the front panel button
indicators.
NOTE: The Esc button does not reset the current configuration or any
presets.
• Indicate that the escape function has been activated (blinks once).
