DXP HD 4K PLUS Series • SIS Configuration and Control 44
X1!
= Output HDCP status
0 = no sink is detected
1 = sink is connected, but does not support
HDCP
2 = sink is connected, supports HDCP, but is
currently not encrypted
3 = sink is connected, supports all HDCP
versions, and is currently encrypted
X1@
= Video mute
0 = unmute
1 = video mute
2 = video and sync mute
X1#
= Audio mute
0 = unmute
1 = HDMI audio mute
2 = Analog audio mute
3 = HDMI and analog audio mute
4 = S/PDIF mute
5 = HDMI audio and S/PDIF mute
6 = Analog audio and S/PDIF mute
7 = HDMI and analog audio, and S/PDIF mute
X1$
= Output mute
0 = unmute
1 = video mute (one or more outputs)
2 = audio mute (one or more outputs)
3 = video and audio mute (one or more outputs)
X1%
= Input attenuation
-20 to 00 in dB (00 = default)
X1^
= Output volume
0 to 100 percent in approximately 1.28 dB intervals
(100 = default)
NOTE: If X1^ exceeds the acceptable volume range specified in the Output
Volume commands on page53, an E13 error message is returned.
X1&
= Global preset number
1-16
X1*
= Room number
1-10
X1(
= Room preset number
1-10
X2)
= Front Panel Lockout
mode
0 = unlock the front panel
1 = mode 1 (complete front panel lockout)
2 = mode 2 (tie configuration and preset
management only, default)
X2!
= HDCP notification —
screen background color
0 = black screen
1 = green screen (default)
X2@
= Signal status
0 = no signal detected
1 = input signal detected
