DXP HD 4K PLUS Series • SIS Configuration and Control 45
X2#
= Verbose mode
0 = None (default for LAN connection)
1 = Verbose mode (default for RS-232 and USB
connection)
2 = Tagged responses to queries
3 = Verbose mode and tagged responses
NOTES:
• In verbose response mode, the DXP
returns unsolicited responses for value
and setting changes that may result from
a signal change, or a setting adjustment
made via another interface.
Example: The DXP can send out a notice
of a change in some setting without
receiving a query via a PC or a control
system. That change could have been a
result of an internal process or a selection
made via the PCS program. This is a
verbose (wordy) relationship between the
controller and a connected device.
• If tagged responses are enabled, all
“view” commands return the command
string plus the data, the same as in
responses for setting a value.
For example:
Command:
X!
*\
Response: Vtyp
X!
*
X#]
(tagged) or
X#]
(untagged)
X2$
= Power save mode
0 = normal operation (default)
1 = limited functionality — disable all functions
except IP, USB, and RS-232, and reduce fan
speed.
To return to mode 0: Press a front panel
button, issue an SIS command, cycle
power, or open PCS.
2 = limited functionality — disable all functions
except IP, USB, and RS-232 ports, and
reduce fan speed. Front panel is non-responsive.
Responds only to SIS viewing commands and
E 0PSAV}.
To return to mode 0: Enter the
E 0PSAV} command or open PCS.
X2%
= Firmware version
n.nn
X2^
= Verbose firmware version
[version]-[description]-[upload date and
time]
X2&
= Power supply In voltage
X2*
= Temperature In degrees Celsius
X2(
= Fan In RPM
X3)
= IP address
nnn.nnn.nnn.nnn
(192.168.254.254 = default)
