DXP HD 4K PLUS Series • SIS Configuration and Control 54
Command ASCII Command
(Host to Switcher)
Response
(Switcher to Host)
Additional Description
Preset Commands
Global Presets
Save global preset
X1&, SprX1&]
Save the current
configuration to a global
preset.
Recall global preset
X1&. RprX1&]
Apply a global preset
configuration.
Directly write global preset
E+X1& P X!*X@ %...X!*X@%}
SprX1&]
Save a specified
configuration to a global
preset in one entry.
NOTE: Before using the direct write of a global preset, always clear that global preset (see EX1&ZG},
below). In a directly written preset, the tied input for each output position (or no tied input) remains
unchanged unless overwritten or cleared. If you do not clear the preset number before directly writing
another preset to it, ties that are part of the previous version may become part of the new preset.
View global HDMI preset
EX1&*01*1VC} X!
1
•
X!
2
•
...X!
16
•
Vid]
View the inputs tied to
each output for a global
preset.
VgpX1&*Out01
•
X!
1
•
...X!
2 or 4
•
...--
16
•
Vid]
Verbose modes 2 and 3:
View global audio preset
EX1&*01*2VC} X!
1
•
...X!
2 or 4
•
...--
16
•
Aud]
View the inputs tied to
each audio-only output for
a global preset.
-- = output is not
applicable.
VgpX1&*Out01
•
X!
1
•
...X!
2 or 4
•
...--
16
•
Aud]
Verbose modes 2 and 3:
Set global preset name
EX1&,X$ NG} NmgX1&,X$]
Set a global preset name.
View global preset name
EX1&NG} X$]
NmgX1&,X$]
View a global preset
name.
Verbose modes 2 and 3
Reset all global presets
EZG} Zpg]
Clear all global presets.
Reset individual preset
EX1&ZG} ZpgX1&]
Clear an individual global
preset.
KEY:
X! = Input number
1 through <maximum number of inputs>
X@ = Output number
HDMI output, 1 through <maximum number of outputs>:
DXP 42 — 1 or 2, DXP 44 and 84 — 1-4, DXP 88 — 1-8
X$ = Name
16 alphanumeric characters ([unassigned] for presets not saved)
X1& = Global preset number 1-16. X1& can be 0 for viewing current ties only.
NOTE:
n
= maximum number of outputs.
